Super DOT LINE 6010 IP

Super DOT LINE 6010 IP

TECHNICAL PARAMETERS

Light source

Voltage: AC100-240V, 50/60Hz

Max Power: 850 W

Source: High brightness 10pcs 60W RGBW 4in1 LED

Effect light: Cool white 96x1w, warm white 96x1w, RGB 3in1 96x1w LED

LED Lifetime: Average 50,000 hours

Optical

Color temperature2500K-9000K

Controls

Channel: 17/27/99/ 108/ 168/ 170 six channel mode

Control mode: DMX-512,RDM,Master-slave,Art-Net(Install with added cost)

DMX signal interface: 3 pin/5 pin input output optional

Screen: 1.77 -inch color LCD display

Software upgrade: update software through DMX connection

Effect

Beam degree: 4 °-38° ,with wash, beam, and macro effect.

Dimmer: 0-100% linear dimmer with 4 kinds of dimmer curve.

Strobe: 1-25 times per second

Construction

Tilt: 270 degree+ fine

IP rate: IP65

Weight&Dimension

Fixture size: 100.2*13.1*37cm

Carton size: 110*22*46cm ( 1pc/ctn)

 NW.: 26 KG

GW.:29KG
