B-EYE 3740 (K25)

TECHNICAL PARAMETERS

Light source

Rated voltage: AC100V～240V 50/60Hz Input power: 1500W

LED: 37*40W 4in1 RGBW LEDs

Authorized life: 30,000 hours

Optical

Color: red, green, blue and white

Focus: 2°-60° DMX linear focus, with auto-focus function

Color temperature control: built-in CTO DMX linear dimming

Electronic strobe, 0.3 ~ 25 times / sec, can choose synchronous, asynchronous random strobe

Dimming: electronic dimming 0 ~ 100%~linear adjustment, with a

flickering, using a stable constant current driver and power supply, suitable for video shooting

Controls

Control interface: DMX512 interface (3-core / optional 5-core), power cord hand socket

Hibernation function: using advanced technology to realize the remote hibernation function, when the lamps and lanterns are

disconnected from the signal automatically enter the hibernation state, so that the lamps and lanterns are more stable and more  secure

Display function: 2.8-inch touch screen, Chinese and English bilingual menu, sensor failure display, temperature display

Effect

Effect Mode: (Swirl, Kaleidoscope, Coloring, Beam)

Front mirror plate variable infinitely rotatable, seamless splicing

mirror plate, aspheric lens structure, lamp beads single point

control control light with effect: strobe, running horse effect, with

built-in programs

Construction

Rotation angle: XY axis adopts high-speed silent 60 thickened

three-phase motor drive, with high-precision imported magnetic

encoding positioning device, so that the operation and positioning is more accurate, when the occurrence of misalignment can be

automatically returned to the position of the horizontal, vertical

speed is adjustable; XY axis rotation function and take the function of the reverse

Heat dissipation system: high conductivity copper tube radiator,

fan intelligent monitoring technology according to the temperature of the lamps and lanterns automatically adjust the fan speed,

built-in overheating protection intelligent system / intelligent temperature and noise balance module

Protection class: IP22

Weight&Dimension

Net weight: 35kg

Features

1. Screen auto-rotate function, the system can automatically  rotate the screen according to the direction of gravity, no need to rotate manually! You can also turn off the automatic rotation function
