MT Wash 3725
MT Wash 3725
TECHNICAL PARAMETERS
Light source
Input voltage range:110-240V~ 50/60Hz
Power consumption:850W
Light source: 37*25W 4-IN-1 RGBW LEDs
Optical
Temperature:6000K
Zoom range:5°-50°
Controls
Control channels :15/331/35
Control protocol: DMX512, RDM
Upgrade: Upgrade via DMX/USB connection
4 touch buttons selecon menu
Display: LED 2.4G color screen
Data in/out: 3-pin and 5-pin XLR
Effect
Dimming/strobe:0%~100% dimming stop/strobe effect with adjustable speed, dual channel with instantaneous power-off funcon for color temperature setting
Strobe: 1 flash/sec., Fast strobe: 25 flashes/sec
Electronic linear zoom system
It integrates powerful beam and dyeing funcons with excellent color macro effect
CTO: 2500K-8000K
Outstanding strobe effect with variable speed
Construction
Pan movement: 540°
Tilt movement: 270°
16-bit precision scanning
Automac Pan/Tilt posion correcon
Power outlets: straight outlet, power connector input, power connector input/output.
Protecon Rang:IP20
2 fixed folding hooks for 50mm truss with keyhole reserved for 70mm truss for removable hooks
Maximum number of connecons: 11 units at 230V and 50Hz, 5 units at 120V and 60Hz
Suitable for stages, theatres, TV studios and dancehalls
Weight&Dimension
Product dimensions: 409x314x469mm
Package size: 490x350x620mm, 19kg(Carton included, one unit per carton)
The flight case is one for two:750x440x700mm, 65kg(Flight case included)
