BSW280 (Pointe)

BSW280 (Pointe)

POWER SUPPLY

Voltage:AC110V~240V/50-60Hz

Ballast:Electronic Ballast

OPTIC

Lamp: Osram Siruis HRI 280W or Yodn MSD R10 280W

Average Lifespan: 2200Hrs

Power consumption: 300W

Lens : high precision optical lens

EFFECT SELCTION

Color wheel: 13 dichroic filters + white

Rotating Gobo Wheel, with 9 bidirectional and indexable gobos (outside diameter: 15,4 mm, image

diameter: 13 mm)

Static Gobo wheel with 14 fixed gobos, at variable rotation

Prism 1: 8-facet circular prism rotating in both directions at different speeds

Prism 2: 6-facet linear prism rotating in both directions at different speeds

Zoom: parallel beam angel 2.8°-38°

Wash effect : adjustable Wash effects angle

Focus: linear adjustment

Dimmer : 0-100% linear adjustment

Strobe : Double lens strobe (0.5-9 times/ second)

MOVEMENT

Pan/Tilt : X axis 540° Y axis 270°automatically accurate positioning

Fixation option: Pan/Tilt-lock mechanism

Control mode : Standard DMX512, Automatic and Master/ slave mode

PROGRAMMING

Channel : 16 CHs / 24 CHs

Controller can open the lamp and reset, including delaying function

WEIGHT&SIZE

Weight : 19kG

Dimension: 386 (L) X 365 (W) X 589 (H) mm
