Halo ALED Beam 350

TECHNICAL PARAMETERS

Light source

Light source:300W LED Moudle+ 36pcsx0.5W RGB SMD LEDS

Life expectancy:50,000 hours

Input voltage range:100-240V~50/60Hz Power consumption:375W

Optical

Advanced optical system ensure clear, sharp image quality High-efficiency optical system

Beam angle:1.5degree

Controls

Protocols: DMX512,Sound Active,Automatic,Master/Slave,RDM DMX modes:1

Control channels:18 channels

Pan/Tilt resolution:16-bit Electronic ballast

Firmware Upgrade via DMX link

Power supply with electronic auto-ranging

Power connector in/out

Data in/out: 3-pin or 5-pin XLR

Effect

Rotation Gobos

1x gobo wheelwith 7gobos plus open

Color Wheel

1x color wheel with 14 colors plus white

Prism

8facet and 6+12 facet

Frost Rainbow Wheel

frost+rainbow effect

Construction

Tilt movement:270°

Pan movement:540°

Automatic Pan/Tilt position correction

Weight&Dimension

Dimensions:340*290*530mm

Weight:15kg
