Mega pointe BSW480

TECHNICAL PARAMETERS

Light source

Light source model: PHILIPS-MSD Silver 480W LL

Maximum power: 800W

Power supply: 100v-240v 50-60Hz

Color temperature: 7800k

Lamp life: 4000 hours

Optical

Beam angle: 2.2 ° - 50 °

Controls

Control mode: DMX512, master-slave operation, sound control

Channel mode: 34CH/ 39CH

Support RDM function, DMX software upgrade function

Optional network function support: artnet, klingnet, sacn, network protocol

Display: Color LCD display

Effect

Color Wheel: 13colors + open, with rainbow effect

Virtual Colour wheel（Linear CMY）

66 preset colours

Static Gobo Wheel: 10 gobos + open, with rotation and running water effect

Rotation gobo wheel:9 gobos+openAnimation Wheel

Frost: With frost effect

Focus: motorized focus

Display: color LCD, Chinese and English display, reverse display

Prism: 2 prism wheel

Prism wheel 1:  Rotating 6-facet linear prism with continuous rotation in both directions

Rotating 8-facet 12° circular prism with continuous rotation in both directions

Rotating cylindrical prism with continuous rotation in both directions

Prism wheel 2

Rotating 6-facet linear prism with continuous rotation in both directions

Rotating 32-facet circular prism with continuous rotation in both directions

Rotating 8-facet 18° circular prism with continuous rotation in both directions

Frost: With frost effect

Focus: motorized focus

Construction

Pan: 540 degree + fine （Magnetic encoder）

Tilt: 270 degree + fine （Magnetic encoder）

Weight&Dimension

Package size:650*600*495MM

Net weight: 21.5kg
